Nice WALKY1024-SKIT Swing Gate Automation Kit (24V DC) for Single Leaf Gates up to 1.8m / 180kg
The Nice WALKY1024-SKIT is a highly compact and efficient swing gate automation solution designed specifically for pedestrian and lightweight residential gates. It uses a 24V DC electromechanical gearmotor with an articulated arm, allowing installation even in tight spaces or where large gate pillars limit movement. This system is ideal for wooden or PVC gates and supports single-leaf gates up to 1.8 metres in length and 180kg in weight. Its surface-mounted design ensures quick and simple installation without the need for extensive ground excavation. The integrated control unit provides advanced functionality including self-learning travel limits, adjustable speed control, deceleration at end positions, and built-in diagnostics for reliable operation. The system also includes safety features such as obstacle detection through motor resistance monitoring and mechanical anti-shear arm design.
KEY FEATURES:
- Compact surface-mounted swing gate automation kit
- Suitable for single gates up to 1.8m and 180kg
- 24V DC electromechanical articulated arm motor
- Ultra-fast opening: approx. 7 seconds to 90°
- Designed for pedestrian and lightweight residential gates
- Ideal for wood and PVC gate materials
- Suitable for narrow posts (around 8cm width)
- Integrated control unit with self-learning programming
- Built-in obstacle detection and safety reversal
- Mechanical anti-shear articulated arm design
- Smooth acceleration and deceleration control
- Easy installation with minimal structural work
